Air Motor Trolley
by ENDO
This type of trolley is powered by air and transports a suspended load horizontally.
You can also combine this trolley with an Air Hoist for use as a crane.
Air motors are safer than electric motors.
You can safely install this type of trolley even in chemical plants or places where hazardous materials are handled.
Specification
| Model | Rated load (kg) |
Air pressure (MPa) (kgf/c㎡) |
Traveling speed (m/min) |
Air consumption (m³/min) (normal) |
Applicable beam width (mm) |
Minimum rotation radius (mm) |
Air inlet | Mass (kg) |
| MTH-1T-5 | 1,000 | 0.4(4) | 20 | 0.55 | 75 | 3,500 | Rc1/2 | Approx.35 |
| 0.5(5) | 25 | 0.6 | 100 125 |
800 | ||||
| 0.6(6) | 28 | 0.65 | ||||||
| MTH-2T-5 | 2,000 | 0.4(4) | 16 | 1.05 | 125 150 |
1,000 | Rc1/2 | Approx.63 |
| 0.5(5) | 17 | 1.3 | ||||||
| 0.6(6) | 18 | 1.6 | ||||||
| MTH-6.3T | 6,300 | 0.4(4) | 17 | 1.05 | 150 175 190 |
2,500 | Rc3/4 | Approx.127 |
| 0.5(5) | 18 | 1.3 | ||||||
| 0.6(6) | 19 | 1.6 |
Correspondence table
| Model | EHL-025TS | EHL-049TS | EHL-05TS | EHL-1TW | EHL-1TS | EHL-2TW | EHL-2.8TS |
| MTH-1T-5 | ● | ● | ● | ● | - | - | - |
| MTH-2T-5 | - | - | - | - | ● | ● | △* |
| MTH-6.3T | - | - | - | - | - | - | ● |
△* Only the top hook of air hoist can be connected on the trolley.
